Bomar Hatches

Hatch Hole cut Trim
Part # Screen
opening out Ring
N1070-10A 15-7/16 x 15-7/16 16-1/2 x 16-1/2” NT2070 NS2070

N1039-10A 19-1/8 x 19-1/8 20-1/4 x 20-1/4” NT2039 NS2039

N1049-10AX 24 x 24” 25-1/8 x 25-1/8” NT2049 NS2049

N1080-10A 17-3/8 x 17-3/8 18-1/2 x 18-1/2 NT2080-BK NS2080

LOW PROFILE EXTRUDED HATCH
- anodized heavy-duty aluminum frames.
- heavy duty acrylic lens.
- height above deck approximately 1".

Hatch Hole Trim
Part # Screen
opening cut out ring
910-10 white GT910-2 GS910-28
9-3/16 x 9-3/16” 9-1/2 x 9-1/2”
910-11 black GT910-1 GS910-18
927-10 white GT927-2 —
12-1/2 x 17-1/2” 17-7/8 x 12-7/8”
927-11 black GT927-1 GS927-18
966-10 white GT966-2
16-5/16 x 16-5/16” 16-7/8 x 16-7/8” GS966-18
966-11 black GT966-1
995-10 white GT995-2
19-1/4 x 19-1/4” 19-3/4 x 19-3/4” --
995-11 black GT995-1

LOW PROFILE MOLDED HATCH
- plastic frame.
- floated acrylic lens.
- trim ring and screen included.

Part # Port opening Hole cut out Overall
G414-SD28 3-1/2 x 13-3/8” 4-1/2 x 14-1/2” 6-1/2 x 16-1/2”
G512-AD28 4 x 11” 5-1/2 x 12-1/2” 7-13/16x14-11/16”
G512-AD27 white portlight with clear lens (same as above) MOLDED PORTLIGHTS
- frame and trim ring molded of high
G715AD28 6 x 14” 7-9/16 x 15-1/2” 9-5/8 x 17-3/4”
impact UV stabilized resin.
GS414-18 black screen - injection molded polycarbonate lens.
GS414-28 white screen - screen
GS512-18 black screen - Stainless Steel hardware.
GS512-28 white screen
GT512D-1 black trim ring
