DOMETIC AIR CON

EDC Air Conditioner

Enjoy ideal temperatures on your boat year-round with Dometic EnviroComfort (ECD)
self-contained air conditioning kit. Offers cooling or heating. EDC kits contain all
components for a complete A/C system. All units have high-velocity blowers with internal
motors. The blower can be rotated to a horizontal or vertical position for easier connection to
the duct. The ECD includes a compact digital control display that features a bright green LED
and large buttons. Units are built on an easy-to-plumb stainless-steel drain pan, and the
pre-installed return-air filter is removable for cleaning. For added installation convenience,
the plastic electrical box can be mounted remotely. 115V Warranty: 1 year
Installation kit (not included) includes ducting, seawater system and lines for the installation

BTU model height width depth weight installation kit
(not included)
6,000 207500306 457.2mm 736.6mm 457.2mm 19.28kg 218000106
10,000 207500310 457.2mm 711.2mm 457.2mm 28.11kg 218000110

16,000 207500316 342.9mm 508mm 285.75mm 28.8kg 218000116

222000245 The Passport I/O Environmental Control Unit is a micro-
processor based controller, designed for the precise control and monitor- A/C Cables
ing of direct expansion and chilled water boat air conditioning systems 222103008 15ft
from Marine Air. The control is dual voltage, operating at both 115 and
230 Volts, 50/60 Hz. In chilled water air handlers, the control is referred 222103009 20ft
to as AH-Passport I/O.

Replacement Seawater Pump

PD5250 5/7/10/12,000 BTU’s - 225-500004

PD 5500 16,000BTU’s - 225-500005
